Brokk SmartPower+ Generation
BROKK 170+
Brokk SmartPower+ Generation
BROKK 170+

Meet the new generation Brokk 170+, the ultimate demolition robot tailor-made for the construction industry.

Despite its unassuming size, this lightweight game-changer packs a punch, boasting a robust breaker and a remarkably powerful — yet nearly silent— concrete crusher. Its compact design allows the Brokk 170+ to effortlessly navigate through standard doorways, while its innovative Brokk SmartPower+ electrical system delivers unparalleled power and proven reliability.

  • Increase in uptime and more power over time
  • Smart sensors and a sophisticated Brokk operator support system
  • Ergonomically designed control box weighing less than 3kg and tilted joysticks
  • Equipped with a 24 kW Brokk SmartPower+ electrical system
  • Operates on a 32 A fuse for efficiency
  • Lightweight and powerful



Brokk SmartPower+
Visual status communication system
Ergonomic control box
Daily maintenance - hoods on
Brokk QuickSwitch
Big size grease container
KategoriSpesifikasi
Performance
Slewing speed10 sec/360°
Transport speed, max.2.1 km/h; 1.3 mph
Climbing inclination, max.30°
Hydraulic system
Hydraulic system capacity85 l; 22.5 US gal
Pump typeVariable load-sensing
System pressure18 MPa; 2611 psi
Increased pressure to attachment23 MPa; 3336 psi
Pump flow 50Hz69 l/min; 18 US gal/min
Pump flow 60Hz83 l/min; 21 US gal/min
Power system
Power technologySmartPower+
Electric motor typeABB
Power*24 kW
Recommended fuse size*63 A
Starting deviceSoft start/Direct start
Control system
Control unitPortable
Signal codeDigital
TransferProfessional radio/Cable
Range, radioUp to 300 m
Weight
Machine weight**1600 kg; 3527 lbs
Recommended attachment weight270 kg; 595 lbs
Noise level
Sound power level LWA***87 dB(A)
Dimensions
Width min.780 mm; 30.7 in
Height min.1254 mm; 49.4 in
Vertical reach (incl. breaker)4800 mm; 189 in
Horizontal reach (incl. breaker)4400 mm; 173 in
