Brokk Demolition Robots
BROKK 170
Brokk Demolition Robots
BROKK 170
Upgrading & smartifying the market leader. Incredible power and surprising accessibility.
The Brokk 170 is the perfect demolition robot for the construction industry. Building on the success of the Brokk 160, this model offers impressive impact with its robust breaker and nearly silent concrete crusher. Compact enough to fit through standard doorways and efficient at only 32 A, the Brokk 170 delivers outstanding power and reliability in a lightweight design.
- Lightweight and powerful
- 24 kW Brokk SmartPower™ electrical system
- Can be operated on 32 A fuse
- Compatible with attachments for Brokk 160
Big size grease container
Brokk unique control system
Daily maintenance - hoods on
SmartPower™
Technical
Attachments
Options
| Kategori | Spesifikasi |
| Performance | |
| Slewing speed | 10 sec/360° |
| Transport speed, max. | 2.1 km/h; 1.3 mph |
| Climbing inclination, max. | 30° |
| Hydraulic system | |
| Hydraulic system capacity | 85 l; 22.5 US gal |
| Pump type | Variable load-sensing |
| System pressure | 18 MPa; 2611 psi |
| Increased pressure to attachment | 23 MPa; 3336 psi |
| Pump flow 50Hz | 69 l/min; 18 US gal/min |
| Pump flow 60Hz | 83 l/min; 21 US gal/min |
| Power system | |
| Power technology | SmartPower |
| Electric motor type | ABB |
| Power* | 24 kW |
| Recommended fuse size* | 63 A |
| Starting device | Soft start/Direct start |
| Control system | |
| Control type | SmartRemote, portable |
| Signal code | Digital |
| Transfer | Professional radio/Cable |
| Range, radio | Up to 300 m |
| Weight | |
| Machine weight** | 1600 kg; 3527 lbs |
| Recommended attachment weight | 270 kg; 595 lbs |
| Noise level | |
| Sound power level LWA*** | 87 dB(A) |
| Dimensions | |
| Width min. | 780 mm; 30.7 in |
| Height min. | 1254 mm; 49.4 in |
| Vertical reach (incl. breaker) | 4800 mm; 189 in |
| Horizontal reach (incl. breaker) | 4400 mm; 173 in |
