Brokk SmartPower+ Generation
BROKK 200+
Brokk SmartPower+ Generation
BROKK 200+
Brochure

The newest generation Brokk 200+ defies its size by accommodating heavier tools to outperform any competition.

Despite its unassuming size, this lightweight game-changer packs a punch, boasting a robust breaker and a remarkably powerful — yet nearly silent— concrete crusher. Its compact design allows the Brokk 170+ to effortlessly navigate through standard doorways, while its innovative Brokk SmartPower+ electrical system delivers unparalleled power and proven reliability.

  • Increase in uptime and more power over time
  • Smart sensors and a sophisticated Brokk operator support system
  • Ergonomically designed control box weighing less than 3kg and tilted joysticks
  • Equipped with a 24 kW Brokk SmartPower+ electrical system
  • Operates on a 32 A fuse for efficiency
  • Lightweight and powerful



Brokk SmartPower+
Visual status communication system
Ergonomic control box
Daily maintenance - hoods on
Brokk QuickSwitch
Big size grease container
KategoriSpesifikasi
Performance
Slewing speed10 sec/360°
Transport speed, max.2.1 km/h; 1.3 mph
Climbing inclination, max.30°
Hydraulic system
Hydraulic system capacity85 l; 22.5 US gal
Pump typeVariable load-sensing
System pressure18 MPa; 2611 psi
System pressure, increased to attachment, max.23 MPa; 3336 psi
Pump flow 50Hz85 l/min; 22.5 US gal/min
Pump flow 60Hz102 l/min; 27 US gal/min
Power system
Power technologySmartPower+
Electric motor typeABB
Power*27.5 kW
Recommended fuse size*63 A
Starting deviceSoft start/Direct start
Control system
Control unitPortable
Signal codeDigital
TransferProfessional radio/Cable
Range, radioUp to 300 m
Weight
Machine weight**2100 kg; 4630 lbs
Recommended max. attachment weight350 kg; 772 lbs
Noise level
Sound power level LWA***87 dB(A)
Dimensions
Width min.780 mm; 30.7 in
Height min.1351 mm; 53.2 in
Vertical reach (incl. breaker)5450 mm; 215 in
Horizontal reach (incl. breaker)5100 mm; 201 in
